CNC plasma flame cutting machine , CNC laser cutting machine for steel plate

Place of Origin CHINA
ब्रांड नाम FSM
प्रमाणन CE, ISO
Model Number WS24
Minimum Order Quantity 1
Delivery Time 30 working days
Supply Ability 20 sets per month
उत्पाद विवरण
Work-piece material Q235A Plasma brand Huayuan or Hypertherm
Control method CNC Software FastCAM
हाई लाइट

लौ काटने की मशीन

,

pipe bevelling machine

एक संदेश छोड़ें
उत्पाद विवरण

1. Our advantage


● High precision cut surface gloss
● Blanking cutting speed is fast.This saves manual
● It is a piece of plate automatic programming. Effective use of. Improve efficiency .My company girder plate welding is adopted. Then fine high-frequency 600 degrees thermostatic hardening and natural cooling. For eliminating stress. Processing. For a long time to ensure cutting accuracy and cutting stability
● High oxygen flame by the preheating technique. Through high pressure oxygen small air preheating plank, instant automatically converted into hyperbaric oxygen cutting without manual adjusting preheating of oxygen and cutting oxygen conversion





2. Features



● This is an cnc flame/oxy/gas cutting machine. This cutter adopts dual drive and lineal guide

● The numerical control straightline cutter can make straight cutting and blanking upon carbon steel sheet quickly and effectively can collocate multiple strip cutting tips ,and the transverse cutting torch

● 38KG Grade Guide ,Economical and easy to use





3. Specification and tech data



Model KCG-A
Effective cutting width 2300-3000mm
Effective cutting length 4000mm(can be extended)
Cutting model Flame/plasma/flame and plasma
Cutting material Carbon steel/mild steel/stainless steel/aluminum
CNC controller Shanghai Jiaoda, Beijing Start,Beijing Starfire, MicroEDGE, Burny
Driven model China good Stepper or Japanese servo
Flame cutting thickness 6-200mm
Plasma cutting thickness According to plasma power source
Programming software Australia FastCAM,TruboNEST
THC Flame(electric THC); Plasma(arc voltage automatic THC)
Longitudinal rail T model rail or 24KG Grade



CNC plasma flame cutting machine , CNC laser cutting machine for steel plate 0
